The Hospital single-two armed electric surgical pendant is a new-style, essential apparatus for modern operating rooms. Its compact and national design ensures high efficiency in surgical environments. It features a powered lift range of 50mm and a 340° rotation, providing doctors with optimal positioning without obstructing the workspace.
Rotating Angle
≤ 340°
Bearing Capacity of Equipment Shelve
≤ 150 kg
Radius Capacity Arm Activities
≥ 750 mm
Braking System
Electromagnetic / Mechanical Brake
Main Functions & Features
High Strength Material
Integrated beam made of aluminum alloy with anti-rust treatment for optimum safety and durability.
Safety Design
Medical gas pipelines and power cables are hidden separately within the column to prevent interference.
Electric Lift
Electric driven lift system works quickly, stably, and quietly for precise height adjustment.
Ergonomic Layout
Streamlined design meets laminar flow requests and utilizes operating room space efficiently.
Standard Configuration
• Medical Gas Outlets: O2*2, VAC*1, Air*1
• Power Sockets: 8 Units
• Internet Interface: RJ45*1
• Equipment Platforms: 2 Units
• IV Pole: 1 Unit
• Storage Drawer: 1 Unit
Frequently Asked Questions
What is the maximum load capacity of this surgical pendant?
The pendant is designed for heavy-duty use with a total load capacity of up to 300kg, while individual equipment shelves can support up to 150kg.
Does the arm support full rotation?
Yes, the swiveling arm supports a 340-degree rotation, and the control box itself can rotate up to 330 degrees for maximum flexibility.
What materials are used in the construction?
The main body and rotating arms are constructed from high-tension aluminum alloy with an anti-rust and high-temperature anti-stain coating.
Is the braking system reliable for surgical precision?
Absolutely. It features a pneumatic or mechanical braking system in the joints to prevent unintentional shifting during delicate procedures.
Can the gas and power configurations be customized?
Yes, the medical gas outlets and electrical sockets can be customized and increased according to the specific requirements of the end users.
Is this pendant suitable for ICU environments?
Yes, it is specifically designed for both Operating Rooms (OR) and Intensive Care Units (ICU) to ergonomically facilitate medical workflows.
