Sy-G076-1 Quick Delivery! Portable IV Infusion Pump Price with Drip Sensor

1 / 5

Sy-G076-1 Quick Delivery! Portable IV Infusion Pump Price with Drip Sensor

Customization:	Available
Certification:	CE, MSDS
Group:	All

Send Inquiry

Product Description

Basic Information

Model NO.

SY-G076-1

Purge Rate

800 Ml/H

Power

Less Than 40va

Mechanical Precision

Within ±2%

Pumping Way

Peristalic Fingers

Transport Package

Carton

Product Overview

SY-G076-1 Portable IV Infusion Pump with Drip Sensor

4.3 inch color LCD with backlight
Three working modes: Rate/Volume/Time mode
Purge, KVO function
Heating and remote control functions
Audible and Visible alarms
Full Alarm System: Infusion Complete, Empty, Faulty Signal, etc.
Calibration function, suitable for any brand disposable IV set

Technical Specifications

Pump Type	Drip type infusion pump
Adjustable Drop Rate	1~400 drops/min (step: 1 drop/min)
Adjustable Volume Rate	1~1200 ml/h
Flow Precision	Within ±3% (Mechanical precision: within ±2%)
KVO Rate	1 ml/h (1~300 ml/h); 3 ml/h (>300 ml/h)
Time Range	1 min~9999 min
Occlusion Alarm	High: 800±200 mmHg; Medium: 500±100 mmHg; Low: 300±100 mmHg
Air Bubble Detector	Ultrasonic wave, sensitivity: >25 μL
Internal Battery	11.1V rechargeable li-ion (>2000mAh), works >4 hours
Dimensions	188 mm(L) * 198 mm(W) * 228 mm(H)
Weight	2.2KG

Environment Requirements

Operation Temp

+5 ~ +40ºC

Storage Temp

-30ºC ~ +55ºC

Relative Humidity

20% ~ 95%

Atmosphere Pressure

70kPa ~ 106kPa

Frequently Asked Questions

What working modes does the SY-G076-1 support?

The pump supports three working modes: Rate mode, Volume mode, and Time mode, providing flexibility for different clinical requirements.

How long does the internal battery last?

The built-in 11.1V rechargeable li-ion battery can operate the pump for more than 4 hours at a flow rate of 25 ml/h after a full 8-hour charge.

Is the pump compatible with different brands of IV sets?

Yes, it features a calibration function that makes it suitable for use with any brand of disposable IV set.

What types of alarms are included for safety?

The device includes audible and visible alarms for Infusion Complete, Empty, Faulty Signal, Misoperation, Occlusion, Door Open, Air Bubble, Low Battery, and AC power off.

What is the flow precision of the device?

The pump offers high flow precision within ±3% when using recommended or calibrated high-quality IV sets, with a mechanical precision of within ±2%.

Can the occlusion alarm threshold be adjusted?

Yes, the occlusion alarm has three levels: High (800 mmHg), Medium (500 mmHg), and Low (300 mmHg) to suit different patient needs.
